Key Features

• 5G Connectivity: Supports Sub-6GHz SA/NSA architectures, providing ultra-fast cellular speeds of up to 3.4 Gbps for downloads and 900 Mbps for uploads. It is also backward compatible with 4G (Cat 20) and 3G networks.

• Wi-Fi 6 Technology: Dual-band Wi-Fi 6 with multi-user MIMO ensures high-speed wireless connectivity, supporting data rates of up to 2402 Mbps on 5 GHz and 576 Mbps on 2.4 GHz.

• Dual SIM with Auto-Failover: Equipped with dual SIM slots, the RUTC50 ensures continuous network availability with automatic failover between SIMs based on predefined criteria such as weak signal or network failure.

• Robust Hardware: The router features a Mediatek Dual-core 1.3 GHz ARM Cortex A53 CPU, 512MB DDR3 RAM, and an anodized aluminium housing, making it durable and reliable in harsh operating environments.

• Comprehensive Network Protocols: Supports a wide range of network protocols including TCP, UDP, IPv4, IPv6, and many others, ensuring compatibility with various networking requirements.

• Advanced VPN Support: Includes multiple VPN options such as OpenVPN, IPsec, GRE, and WireGuard, allowing secure and flexible remote connections.

• Enhanced Security: Features such as pre-shared keys, digital certificates, and multiple firewall configurations provide robust security, ensuring safe and secure network operations.

• GNSS for Precise Location Tracking: Supports GPS, GLONASS, BeiDou, Galileo, and QZSS, enabling precise and reliable location tracking, which is critical for mobile and remote operations.

Applications

The RUTC50 is designed for demanding applications where reliable and high-speed wireless communication is crucial. Its use cases include:

• Industrial Automation: Facilitates seamless communication in automated systems, ensuring minimal downtime and robust data transfer.

• Remote Monitoring: Ideal for deploying in remote locations to monitor and manage industrial systems, utilities, and infrastructure.

• Mobile and Public Safety Networks: Ensures reliable communication in mobile networks, including emergency services and public safety operations.

• Smart Cities: Supports the backbone of smart city infrastructure, enabling connected systems for transportation, utilities, and public services.

Connectivity and Management

• Ethernet Ports: Five Gigabit Ethernet ports for high-speed wired connections.

• Remote Management: Compatible with Teltonika's Remote Management System (RMS), allowing for centralized configuration, monitoring, and management of devices.

• Powering Options: The device can be powered through a 4-pin industrial DC power socket or via passive PoE, offering flexibility in installation.

• I/O Interfaces: Includes digital input/output options, making it versatile for various industrial applications.

Installation and Configuration

• Compact Design: The RUTC50 has a compact form factor (130.4 x 42.6 x 103.4 mm) and can be mounted on a DIN rail, wall, or flat surface, ensuring easy installation in various environments.

• Operating Environment: Built to operate in extreme conditions, with an operating temperature range of -40°C to 75°C and an IP30 rating, making it suitable for both indoor and outdoor use.
